Constant temperature controller SCC30
The SCC30 Constant Temperature Controller is used to control the return temperature of solid fuel boilers, to fill the heat storage tank, to control a pellet or chimney boiler.
Key features of the SCC30 constant temperature controller
- Adjustable return temperature.
- Boiler overheating protection.
- Graphical display of temperatures by day for the last week.
- Measurement and display of the energy generated.
- Diagnostics only, with fault warning and notification when temperatures are exceeded.
- 2 preset hydraulic schemes.
- One-step filling of the feeder.
- Free programmable up to 1 unused output.
- Possibility to adjust the mixing valve according to the temperature of the pipeline and the source.
- Simulation of system operation.
| COMPARING THE PERFORMANCE OF CONTROLLERS | SCC30 | SCC40 |
|---|---|---|
| USE | ||
| For regulating the return temperature of solid fuel boilers | Yes | Yes |
| Filling storage tanks | Yes | Yes |
| Pellet or combi boiler control | Yes | Yes |
| TECHNICAL CHARACTERISTICS | ||
| Number of preset hydraulic schemes | 2 | 6 |
| Number of storage tanks | 1 | 2 |
| Number of mechanical relays | 2 | 4 |
| Number of electronic relays | 2 | 2 |
| Number of inputs for temperature sensors | 7 | 7 |
| Additional sensor for source temperature measurement | Yes | Yes |
| Possibility to adjust the mixing valve according to the pipeline and source temperature | Yes | Yes |
| Possibility to regulate the pump according to the pipeline and source temperature | Yes | Yes |
| Measuring the energy generated (kW/h) | Yes | Yes |
| Flow measurement option with pulse meter (l/min) | Yes | Yes |
| Free programming option | 1 exit | up to 3 outputs |
| REGULATING SYSTEMS | ||
| One-step filling of the feeder | No | Yes |
| Two-stage filling of the feeder | No | Yes |
| REGULATING HEAT SOURCES | ||
| Pellet boiler | Yes | Yes |
| HEATING SYSTEM PROTECTION | ||
| Boiler overheating protection | Yes | Yes |
| Anti-blocking function for pumps | Yes | Yes |
| Anti-blocking function for pumps and diverter valves | No | Yes |
| A COMPREHENSIVE OVERVIEW OF THE HEATING SYSTEM'S OPERATION | ||
| Graphical display of temperatures by day for the last week | Yes | Yes |
| Detailed display of temperatures for the current day | Yes | Yes |
| Notifications of activated safety functions and system fault warnings | Yes | Yes |
| Possibility to simulate sensors and analyse system performance | Yes | Yes |
| REMOTE ACCESS | ||
| USB connection to a PC | Yes | Yes |
| SET-UP AND INSTALLATION | ||
| Wizard for easy and fast device start-up | Yes | Yes |
| 13 language user interface EN, DE, FR, NL, PL, ES, SL, IT, CS, LT, GR, HU, HR | Yes | Yes |
| Setting the operation by selecting the hydraulic scheme | Yes | Yes |
| "Help" key for quick help with settings | Yes | Yes |
| Graphically configurable time programmes | Yes | Yes |
| Possibility to simulate system operation | Yes | Yes |
| Logging and displaying changes to settings | Yes | Yes |
| Basic settings can be retrieved in case of loss or unwanted changes | Yes | Yes |
| Possibility to programme free outputs | Yes | Yes |
| Wall or DIN-rail mountable | Yes | Yes |
| Easy installation and connection | Yes | Yes |
| TECHNICAL DATA | SCC30 |
|---|---|
| Operating temperature | 5÷40 °C |
| Storage temperature | -20÷65 °C |
| Product weight | 410 g |
| Number of pieces per packing unit | 6 pieces |
| Dimensions (W × H × D): 113 x 163 x 48 mm |  |
| Electrical connection |  |
| Illuminated graphic display | Yes |
| Operating hours counter | Yes |
| Programme clock | Yes |
| Connection voltage | 230 V ~, 50 Hz |
| Energy consumption | 2,5 W |
| Standby power consumption | Maximum 0,5 W |
| Number of entrances | 7x temperature sensor (Pt 1000) 1 x pulse input |
| Number of outputs | 2 x triac (R2,R3) 2 x relays ( R1,R4) |
| Relay outputs | 4 (1) A ~, 230 V ~ |
| Triac outputs | 1 (1) A ~, 230 V ~ |
| Clock power supply | Battery CR2032 (Li-Mn) 3 V |
| Time display accuracy | +/- 1 s (24 h) at 20 °C |
| Degree of protection | And after P20 / EN60529 |
| Safety class | I according to EN 60730-1 |
| Type of operation | 1B to EN 60730-1 |
| Type of temperature sensors | Pt1000 or KTY10 |
| Housing material | ASA - thermoplastic |
